Digital Vernier Height Gauge, 0-500mm, 0.01mm

Cheap high precision digital vernier height gauge for sale online, which with 0-500mm measuring range, error ±0.05mm, and resolution of 0.01mm. LCD digital readout of electronic digital height gauge displays figures in inches or metric units for viewing ease.

SKU: CCHN-DHG-500

30-day Returns

Free Shipping

Delivery date: 6-25 days

Overview

Order a 500mm digital height gauge, the height gauge is a measuring device used to provide very precise height measurements. It comes with an error of ±0.05mm, a resolution of 0.01mm, and a voltage of 1.5V.

Specification

Model: CCHN-DHG-500
Range: 0-500mm
Voltage: 1.5V

Resolution: 0.01mm
Error: ±0.05mm
Responding Speed: 1 m/s

Body Material: 4CR13 stainless steel
Battery Type: 1.5 button battery
Weight: 26kg

Dimension (mm)

Dimension of digital height gauge

Details

Digital Height Gauge Details

Application

CCHN digital height gauges are also called height gauges. As the name suggests, its main purpose is to measure the height of workpieces, and it is also often used to measure shape and position tolerances, and sometimes to mark lines. Digital height gauges are mainly used in the automotive industry, manufacturing, science, and research industries.

Application of digital height gauge

Tips: Working principle of a digital height gauge

Digital counter height gauges combine a dial and needle as found on the dial height gauge type with a dual-digit counter to increase the speed and efficiency of the measurement process. The counter will allow readings to tenths of an inch while thousandths of an inch can be read on the dial.
