4 HP Pool Pump, 220V / 380V

4 hp pool pump with cheap price for sale. Pool pump adopts 100% copper motor. The medium temperature of portable pool pump between 5 ℃ and 50 ℃.

Feature:

• Magnificent flow rate and lift, the core energy of water circulating, 2-3m suction lift.
• Free-tool filter cover design, easy to maintenance.
• IP55 protection level, with none-leaky design.
• 100% copper wire motor, 24 hours running.
• Silicone sealing ring, cover all watering section, enhance pump sealing system.
• Engineering plastic body, pump can be effectively protected under bad weather, long service life.
• Anti rust cast-aluminum motor cover,fast heat dissipation; PPO plastic steel material impeller, resist high temperature and corrosion.

Specification:

• Model: CCHN-FLB-40
• Voltage: 220V / 380V (3 phase)
• Frequency: 50 Hz / 60 Hz
• Power: 4 HP (3 kW)
• Hmax: 18m
• Qmax: 48 m^3/h
• Port Size: 90 mm
• Threaded Connection: G 1-1/2"
• Motor: copper motor
• Medium Temperature: 5 ℃ - 50 ℃
• Protection Level: IP55
• Weight: 26 kg

Dimension (Unit: mm)

Flow Diagram:

Details

Application:

Tips: Pool Pump Troubleshooting

• Motor will not start. If the motor hums but doesn't start, you're likely dealing with a jammed impeller. This can happen when the impeller gets clogged with debris. Open the pump and clear the blockage.
• Motor shuts off. First, check to see if there's a low voltage issue, or if there's a power drop happening at the motor on your variable speed pool pump. This is most frequently caused by undersized wiring.
