1 hp (750W) Submersible/Deep Water Well Pump, 72VDC

1 hp deep well water pump with single-suction plastic/ stainless steel impeller, 50/ 70cm length can be chosen, brushless DC motor internal motor. The submersible well pump has advantages of low noise, simple structure and long service life.

Well Pump Features

Controller Features

Package included

• 1 * Water well pump with 2m cable
• 1 * DC controller
• 1 * Stainless steel float switch (water level sensor for the tank)
• 1 * Pump outlet joint connector
• 1 * Splice kit for cable join
• 1 * Splice kit for waterproof
• 1 * User manual

750W 48V DC water well pump performance curves:

Max. Flow: 3.5m³/h, Max. Head: 95m, Model: 3DPC3.5-95-72-750

Max. Flow: 4.8m³/h, Max. Head: 95m, Model: 3DSC4.8-95-72-750

Max. Flow: 6.0m³/h, Max. Head: 56m, Model: 4DPC6-56-72-750

Max. Flow: 5.0m³/h, Max. Head: 67m, Model: 4DSC5-67-72-750

Tips: How to Install the Water Well Pump?

1. The installation position of the water pump should meet the requirements of the allowable vacuum height, and the foundation must be level and stable to ensure that the rotation direction of the power machinery is consistent with the rotation direction of the water pump.
2. If there are multiple units in the same room, there should be a distance of more than 800mm between the units and between the units and the wall.
3. The suction pipe of the pump must be well-sealed, and elbows and gate valves should be minimized. Air should be exhausted when filling and diverting water. Air should not accumulate in the pipe during operation. There is a certain submerged depth.
